Product Description

Technical Data

Material: E-Cu
Surface treatment: Tin-plated
Product Property: It is used to connect the copper conductor end. It has a viewing window to check the conductor location.

Model

L Dimensions(mm) d Φ









JM(JGK)6-5

25

3.7

5.2

JM(JGK)6-6

25

3.7

6.5

JM(JGK)6-8

25

3.7

8.4

JM(JGK) 10-5

26

4.5

5.3

JM(JGK) 10-6

26

4.5

6.5

JM(JGK) 10-8

26

4.5

8.4

JM(JGK) 10-10

28

4.5

10.3

JM(JGK) 16-6

28.5

5.7

6.5

JM(JGK) 16-8

30.5

5.7

8.4

JM(JGK) 16-10

31

5.7

10.5

JM(JGK) 25-6

35

7.2

6.5

JM(JGK) 25-8

35

7.2

8.4

JM(JGK) 25-10

35

7.2

10.5

JM(JGK) 35-6

37.5

8.5

6.5

JM(JGK) 35-8

38

8.5

8.5

JM(JGK) 35-10

39

8.5

10.5

JM(JGK) 35-12

39

8.5

13

JM(JGK) 50-6

43.5

9.8

6.5

JM(JGK) 50-8

45

9.8

8.5

JM(JGK) 50-10

45

9.8

10.5

JM(JGK) 50-12

45

9.8

13

JM(JGK) 50-14

45

9.8

14.5

JM(JGK) 70-8

50

11.5

8.5

JM(JGK) 70-10

51.5

11.5

10.5

JM(JGK) 70-12

51.5

11.5

13

JM(JGK) 95-8

58.5

13.7

8.5

JM(JGK) 95-10

58.5

13.7

10.5

JM(JGK) 95-12

58.5

13.7

13



Model

L Dimensions(mm) Φ d









JM(JGK) 120-10

63.5

15

10.5

JM(JGK) 120-12

65

15

13

JM(JGK) 120-14

65

15

14.7

JM(JGK) 120-16

66.5

15

17

JM(JGK) 150-10

73

16.7

10.5

JM(JGK) 150-12

73

16.7

13

JM(JGK) 150-14

73

16.7

14.7

JM(JGK) 150-16

73

16.7

17

JM(JGK) 185-10

80

19.2

10.5

JM(JGK) 185-12

80

19.2

13

JM(JGK) 185-14

80

19.2

14.7

JM(JGK) 185-16

80

19.2

17

JM(JGK) 240-12

92.5

21

13

JM(JGK) 240-14

92.5

21

14.7

JM(JGK) 240-16

92.5

21

17

JM(JGK) 240-20

94.5

21

21

JM(JGK) 300-12

102

24

13

JM(JGK) 300-16

102

24

17

JM(JGK) 300-20

105

24

21

JM(JGK) 400-16

114

27

17

JM(JGK) 400-20

116

27

21

JM(JGK) 500-16

127

30

17

JM(JGK) 500-20

127

30

21

JM(JGK) 630-16

140

35

17

JM(JGK) 630-20

140

35

21

JM(JGK) 630-22

140

35

23

JM(JGK) 800-22

170

39

23

JM(JGK) 1000-22

200

44

23



Technical Data

Material: E-Cu
Surface treatment: Tin-plated
Product Property: It is used to connect the copper conductor end. It has a viewing window to check the conductor location.And its bell mouth is specially designed to accommodate fine strand flexible conductors. Because fine stranded cables have a larger diameter than normal calbes. And they tend to splay out after stripping, JGB lugs which funnel the strands into the lug and make conductor insert easily.

Model

L Dimensions(mm)d Φ









JM(JGK)6-5

25

3.7

5.2

JM(JGK)6-6

25

3.7

6.5

JM(JGK)6-8

25

3.7

8.4

JM(JGK) 10-6

26

4.5

6.5

JM(JGK) 10-8

26

4.5

8.4

JM(JGK) 10-10

28

4.5

10.3

JM(JGK) 16-6

28.5

5.7

6.5

JM(JGK) 16-8

30.5

5.7

8.4

JM(JGK) 16-10

31

5.7

10.5

JM(JGK) 25-6

33.5

7.2

6.5

JM(JGK) 25-8

35

7.2

8.4

JM(JGK) 25-10

35

7.2

10.5

JM(JGK) 35-6

37.5

8.5

6.5

JM(JGK) 35-8

38

8.5

8.5

JM(JGK) 35-10

39

8.5

10.5

JM(JGK) 35-12

39

8.5

13

JM(JGK) 50-6

43.5

9.8

6.5

JM(JGK) 50-8

45

9.8

8.5

JM(JGK) 50-10

45

9.8

10.5

JM(JGK) 50-12

45

9.8

13

JM(JGK) 70-8

50

11.5

8.5

JM(JGK) 70-10

51.5

11.5

10.5

JM(JGK) 70-12

51.5

11.5

13



Technical Data

Material: E-Cu; Al-99.6%
Surface treatment: Bright
Products property: Due to the coupling effect when Aluminium comes in contact with Copper, corrosion will happen in a short time. Currently the best solution is to use Aluminium-Copper bimetal connectors. A bimetal lug should be used for termination. The friction welding is well done. And its barrel capped is filled with joint compound to avoid oxidization.

Model

L Dimensions(mm)





d

B

Φ

DTL 10-6

62

4.8

13.5

6.5

DTL 16-8

70

5.8

16

8.5

DTL 25-8

75

7.2

17.5

8.5

DTL 35-10

85

8.5

20

10.5

DTL 50-10

90

9.7

23

10.5

DTL 70-12

102

11.5

26

12.5

DTL 95-12

112

13.5

28

12.5



Model

Dimensions(mm)



L

d

B

Φ

DTL 120-14

120

15

31

14.5

DTL 150-14

125

16.5

35

14.5

DTL 185-16

133

18.5

37.5

17

DTL 240-16

140

21

40

17

DTL 300-18

160

23.5

44.5

18.5

DTL 400-20

170

27

50

21

DTL 500-20

225

29

60

21



Technical Data

Products property: Due to the coupling effect when Aluminium comes in contact with Copper, corrosion will happen in a short time. Currently the best solution is to use Aluminium-Copper bi-metal connectors. A bimetal lug should be used for termination. The friction welding is well done. And its barrel capped is filled with joint compound to avoid oxidization. The type test is follow IEC 61238-1.

Model DTL-2-16-11

P±0.3 D±0.5 d Dimensions(mm)0.3 W±0.5 S±0.3

±0.3   L±3  L1±



Φ11

Φ16

Φ6

80

40

Φ20

3

DTL-2-25-11

Φ11

Φ16

Φ7

80

40

Φ20

3

DTL-2-35-11

Φ11

Φ16

Φ8.5

80

40

Φ20

3

DTL-2-50-13

Φ13

Φ20

Φ10

90

43

Φ25

4.5

DTL-2-70-13

Φ13

Φ20

Φ11.5

90

43

Φ25

4.5

DTL-2-95-13

Φ13

Φ20

Φ13.5

90

43

Φ25

4.5

DTL-2-120-13

Φ13

Φ25

Φ15

115

59

Φ30

5.5

DTL-2-150-13

Φ13

Φ25

Φ16.5

115

59

Φ30

5.5



Model DTL-2-185-13

P±0.3 D±0.5 d Dimensions(mm)0.3 W±0.5 S±0.3

±0.3   L±3  L1±



Φ13

Φ32

Φ18.5

122

60

Φ30

6

DTL-2-240-13

Φ13

Φ32

Φ21

122

60

Φ35

6

DTL-2-300-13

Φ13

Φ34

Φ23.5

128

65

Φ35

6

DTL-2-400-17

Φ17

Φ40

Φ26

160

90

Φ36

6

DTL-2-500-17

Φ17

Φ40

Φ30

160

95

Φ36

6

DTL-2-630-17

Φ17

Φ47

Φ33.5

205

95

Φ60

10

DTL-2-800

Φ17

Φ60

Φ38.5

240

110

Φ80

10

DTL-2-1000

Φ17

Φ60

Φ43.5

240

110

Φ80

10



Technical Data

Material: E-Cu
Surface treatment: Tin-plated
Product property: It is used to connect copper conductor joint.

Model GTY-1-1.5

LDimensions(mm)d



20

1.9

GTY-1-2.5

20

2.8

GTY-1-4

20

3.2

GTY-1-6

25

3.7

GTY-1-10

30

4.5

GTY-1-16

35

5.7

GTY-1-25

40

7.2

GTY-1-35

45

8.5

GTY-1-50

50

9.8

GTY-1-70

55

11.5

GTY-1-95

60

13.7



Model GTY-1-120

LDimensions(mm)d



65

15

GTY-1-150

70

16.7

GTY-1-185

75

19.2

GTY-1-240

80

21

GTY-1-300

85

24

GTY-1-400

90

27

GTY-1-500

100

30

GTY-1-630

110

35

GTY-1-800

150

39

GTY-1-1000

170

44



Technical Data

Material: E-Cu; Al-99.6%
Surface treatment: Bright
Product property: Due to the coupling effect when Aluminium comes in contact with Copper, corrosion will happen in a short time. Currently the best solution is to use Aluminium-Copper bimetal connectors. A bimetal link should be used for joint.
The friction welding is well done. And its aluminium barrel capped is filled with joint compound to avoid oxidization.

Model GTL-AL25/CU16

L Dimensions(mm) d d1



70

6.8

5.5

GTL-AL35/CU16

76

8

5.5

GTL-AL35/CU25

82

8

7

GTL-AL50/CU25

85

9.8

7

GTL-AL50/CU35

90

9.8

8.2

GTL-AL70/CU35

95

11.2

8.2

GTL-AL70/CU50

100

11.2

10

GTL-AL95/CU50

105

13.2

10

GTL-AL95/CU70

110

13.2

11.5

GTL-AL120/CU70

116

14.7

11.5



Model GTL-AL120/CU95

L Dimensions(mm) d1d



118

14.7

13.5

GTL-AL150/CU95

120

16.3

13.5

GTL-AL150/CU120

122

16.3

15.5

GTL-AL185/CU120

128

18.3

15.5

GTL-AL185/CU150

130

18.3

17

GTL-AL240/CU150

132

21

17

GTL-AL240/CU185

135

21

19

G TL-AL240/CU240

140

21

21.5

GTL-AL300/CU240

145

23.3

21.5

GTL-AL300/CU300

150

23.3

21.5
